Supermicro SuperServer 1029P-WTRT Intel C622 LGA 3647 Socket P Rack 1U Black

The Supermicro SuperServer 1029P-WTRT features an Intel C622 motherboard chipset and utilizes the LGA 3647 (Socket P) processor socket. It offers a system bus rate of 10.4 GT/s. The server supports DDR4-SDRAM memory types and can accommodate a maximum internal memory of 1.5 TB, with a maximum RDIMM memory capacity of 768 GB. For storage, it supports Serial ATA III drive interfaces and RAID levels 0, 1, 5, and 10. It includes an on-board graphics card model Aspeed AST2500. The server is equipped with copper ethernet cabling technology that supports 10GBASE-T.

Processor

Built-in processor
Built-in processor
No
show more


Motherboard chipset
Motherboard chipset
Intel C622
show more


Processor socket
Processor socket
LGA 3647 (Socket P)
show more


Number of processors supported
Number of processors supported
2
show more


System bus rate
System bus rate
10.4 GT/s
show more


Compatible processor series
Compatible processor series
Intel® Xeon®
show more

Memory

Number of DIMM slots
Number of DIMM slots
12
show more


Supported memory types
Supported memory types
DDR4-SDRAM
show more


Maximum internal memory
Maximum internal memory
1.5 TB
show more


Maximum RDIMM memory
768 GB
show more


Supported RDIMM clock speeds
2133,2400,2666 MHz
show more


ECC
ECC
Yes
show more

Storage

Number of storage drives supported
Number of storage drives supported
8
show more


Hot-swap HDD bays
Hot-swap HDD bays
Yes
show more


Supported storage drive interfaces
Serial ATA III
show more


RAID levels
RAID levels
0, 1, 5, 10
show more

Graphics

On-board graphics card model
On-board graphics card model
Aspeed AST2500
show more

Network

Ethernet LAN
Ethernet LAN
Yes
show more


Copper ethernet cabling technology
10GBASE-T
show more

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
6
show more


Ethernet LAN (RJ-45) ports
Ethernet LAN (RJ-45) ports
2
show more


IPMI LAN (RJ-45) port
Yes
show more


VGA (D-Sub) ports quantity
VGA (D-Sub) ports quantity
1
show more


Number of SATA III connectors
Number of SATA III connectors
8
show more

Expansion slots

PCI Express slots version
3.0
show more


PCI Express x8 slots
1
show more


PCI Express x16 slots
3
show more

Features

PC health monitoring
CPU, Fan, Temperature
show more


Backplanes support
Yes
show more

Technical details

Compliance certificates
RoHS
show more

Logistics data

Harmonized System (HS) code
84714100
show more

BIOS

BIOS type
BIOS type
AMI
show more


BIOS memory size
32 Mbit
show more

Design

Chassis type
Chassis type
Rack (1U)
show more


Product colour
Product colour
Black
show more


LED indicators
HDD, Network, Power
show more


On/off switch
On/off switch
Yes
show more


Fan diameter
Fan diameter
4 cm
show more


Number of fans
Number of fans
6 fan(s)
show more

Power

Power supply
Power supply
750 W
show more


Redundant power supply (RPS) support
Redundant power supply (RPS) support
Yes
show more


Number of redundant power supplies installed
2
show more

Operational conditions

Storage relative humidity (H-H)
5 – 95%
show more


Operating relative humidity (H-H)
8 – 90%
show more


Storage temperature (T-T)
Storage temperature (T-T)
-40 – 60 °C
show more


Operating temperature (T-T)
Operating temperature (T-T)
10 – 35 °C
show more

Weight & dimensions

Weight
Weight
20.9 kg
show more


Height
Height
43 mm
show more


Depth
Depth
597 mm
show more


Width
Width
437 mm
show more
