Supermicro SYS-510P-MR UP 1U X12SPO-F, CSE-813MF2TQC-R407CB, RoHS

The Supermicro SYS-510P-MR features the Intel® Xeon® 3000 Sequence processor family, providing reliable computing performance. It uses DDR4-SDRAM for internal memory, ensuring efficient data handling and multitasking capabilities. This server comes with Ethernet LAN connectivity, allowing seamless network integration. It is equipped with a 400 W power supply and supports redundant power supply (RPS) to enhance system reliability and uptime. Designed to fit in a 1U rack, this chassis type is ideal for space-constrained environments while maintaining powerful performance.

Processor

Processor manufacturer
Processor manufacturer
Intel
show more


Processor family
Processor family
Intel® Xeon® 3000 Sequence
show more


Processor cache
60 MB
show more


Motherboard chipset
Motherboard chipset
Intel® C621
show more


Intelligent Platform Management Interface (IPMI) support
Yes
show more

Memory

Internal memory type
Internal memory type
DDR4-SDRAM
show more


Memory clock speed
Memory clock speed
3200 MHz
show more


ECC
ECC
Yes
show more


Memory slots
Memory slots
8
show more


Maximum internal memory
Maximum internal memory
3 TB
show more

Storage

SSD interface
SSD interface
NVMe, SATA III
show more


NVMe
NVMe
Yes
show more


Supported SSD sizes
3.5"
show more


SSD size
3.5"
show more


Number of SSDs supported
4
show more


RAID support
RAID support
Yes
show more


RAID levels
RAID levels
0, 1, 5, 10
show more


Hot-swap
Yes
show more


Optical drive type
Optical drive type
No
show more

Graphics

On-board graphics card
On-board graphics card
Yes
show more

Network

Wi-Fi
Wi-Fi
No
show more


Ethernet interface type
Gigabit Ethernet
show more


LAN controller
Intel® I350
show more


Ethernet LAN
Ethernet LAN
Yes
show more

Ports & interfaces

Ethernet LAN (RJ-45) ports
Ethernet LAN (RJ-45) ports
3
show more


USB 2.0 ports quantity
USB 2.0 ports quantity
6
show more


USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
5
show more


Serial ports quantity
Serial ports quantity
2
show more


VGA (D-Sub) ports quantity
VGA (D-Sub) ports quantity
1
show more

Expansion slots

PCI Express x16 slots
1
show more

Design

Chassis type
Chassis type
Rack (1U)
show more


Product colour
Product colour
Black
show more


Rack mounting
Rack mounting
Yes
show more

Performance

Remote Name Daemon Control (RNDC)
No
show more


Trusted Platform Module (TPM)
No
show more


BIOS type
BIOS type
EEPROM
show more

Software

Operating system installed
Operating system installed
No
show more

Power

Redundant power supply (RPS) support
Redundant power supply (RPS) support
Yes
show more


Power supply
Power supply
400 W
show more


Power supply input voltage
240 V
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
10 – 35 °C
show more


Storage temperature (T-T)
Storage temperature (T-T)
-40 – 70 °C
show more


Operating relative humidity (H-H)
8 – 90%
show more


Storage relative humidity (H-H)
5 – 95%
show more

Certificates

Certification
80 PLUS Platinum Level
show more

Logistics data

Harmonized System (HS) code
84714100
show more

Sustainability

Sustainability compliance
Yes
show more

Weight & dimensions

Width
Width
437 mm
show more


Height
Height
43 mm
show more


Depth
Depth
507 mm
show more


Weight
Weight
8 kg
show more


Package width
Package width
609.6 mm
show more


Package depth
Package depth
749.3 mm
show more


Package height
Package height
215.9 mm
show more


Package weight
Package weight
13.8 kg
show more

Technical details

Compliance certificates
REACH, RoHS
show more
