Supermicro SYS-620P-TR X12DPI-N6-P, 825BTS-R1K03LPP1, 2U X12 SATA Mainstream Server

The Supermicro SYS-620P-TR is equipped with the Intel® Xeon® 3000 Sequence processor family. It supports DDR4-SDRAM as its internal memory type. For connectivity, it includes an Ethernet LAN. The system features a DVD-ROM optical drive. It is powered by a 1200 W power supply and includes support for a redundant power supply (RPS). The chassis is a 2U rack type, making it suitable for various server applications.

Processor

Processor manufacturer
Processor manufacturer
Intel
show more


Processor family
Processor family
Intel® Xeon® 3000 Sequence
show more


Motherboard chipset
Motherboard chipset
Intel® C621
show more


Intelligent Platform Management Interface (IPMI) support
Yes
show more

Memory

Internal memory type
Internal memory type
DDR4-SDRAM
show more


Memory clock speed
Memory clock speed
3200 MHz
show more


ECC
ECC
Yes
show more


Memory slots
Memory slots
16
show more


Maximum internal memory
Maximum internal memory
4 TB
show more

Storage

SSD interface
SSD interface
SATA III
show more


Supported SSD sizes
3.5"
show more


SSD size
3.5"
show more


Number of SSDs supported
8
show more


RAID support
RAID support
Yes
show more


RAID levels
RAID levels
0, 1, 5, 10
show more


Hot-swap
Yes
show more


Optical drive type
Optical drive type
DVD-ROM
show more

Graphics

On-board graphics card
On-board graphics card
Yes
show more

Network

Wi-Fi
Wi-Fi
No
show more


Ethernet interface type
Gigabit Ethernet
show more


LAN controller
Intel® I350
show more


Ethernet LAN
Ethernet LAN
Yes
show more

Ports & interfaces

Ethernet LAN (RJ-45) ports
Ethernet LAN (RJ-45) ports
2
show more


USB 2.0 ports quantity
USB 2.0 ports quantity
2
show more


USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
show more


Serial ports quantity
Serial ports quantity
2
show more


VGA (D-Sub) ports quantity
VGA (D-Sub) ports quantity
1
show more

Expansion slots

PCI Express x8 slots
2
show more


PCI Express x16 slots
4
show more

Design

Chassis type
Chassis type
Rack (2U)
show more


Product colour
Product colour
Black
show more


Redundant fans support
Yes
show more


Rack mounting
Rack mounting
Yes
show more

Performance

Remote Name Daemon Control (RNDC)
No
show more


Trusted Platform Module (TPM)
No
show more


BIOS type
BIOS type
EEPROM
show more

Software

Operating system installed
Operating system installed
No
show more

Power

Redundant power supply (RPS) support
Redundant power supply (RPS) support
Yes
show more


Power supply
Power supply
1200 W
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
10 – 35 °C
show more


Storage temperature (T-T)
Storage temperature (T-T)
-40 – 60 °C
show more


Operating relative humidity (H-H)
8 – 90%
show more


Storage relative humidity (H-H)
5 – 95%
show more

Certificates

Certification
80 PLUS Titanium Level
show more

Logistics data

Harmonized System (HS) code
84714100
show more

Sustainability

Sustainability compliance
Yes
show more

Weight & dimensions

Width
Width
437 mm
show more


Height
Height
89 mm
show more


Depth
Depth
647 mm
show more


Weight
Weight
16.1 kg
show more


Package width
Package width
678.2 mm
show more


Package depth
Package depth
876.3 mm
show more


Package height
Package height
289.6 mm
show more


Package weight
Package weight
31.2 kg
show more

Technical details

Compliance certificates
REACH, RoHS
show more
