Supermicro SuperWorkstation 7049A-T Intel C621 LGA 3647 (Socket P) Rack 4U Black

The Supermicro SuperWorkstation 7049A-T is equipped with the Intel C621 motherboard chipset. It features a processor socket type of LGA 3647 (Socket P) and offers a system bus rate of 10.4 GT/s. This workstation supports DDR4-SDRAM memory types, with a maximum internal memory capacity of 2 TB and a maximum RDIMM memory of 512 GB.

The SuperWorkstation accommodates storage drive sizes of 3.5 inches and supports Serial ATA III storage drive interfaces. It offers RAID level support for 0, 1, 5, and 10. The on-board graphics card model is the Aspeed AST2500, providing efficient graphics performance. For network connectivity, it includes both Fast Ethernet and Gigabit Ethernet interfaces, offering Ethernet LAN data rates of 10, 100, and 1000 Mbit/s.

Processor

Built-in processor
Built-in processor
No
show more


Motherboard chipset
Motherboard chipset
Intel® C621
show more


Processor socket
Processor socket
LGA 3647 (Socket P)
show more


Number of processors supported
Number of processors supported
2
show more


System bus rate
System bus rate
10.4 GT/s
show more


Compatible processor series
Compatible processor series
Intel® Xeon®
show more

Memory

Number of DIMM slots
Number of DIMM slots
16
show more


Supported memory types
Supported memory types
DDR4-SDRAM
show more


Maximum internal memory
Maximum internal memory
2 TB
show more


Maximum RDIMM memory
512 GB
show more


Supported RDIMM clock speeds
2133,2400,2666 MHz
show more


ECC
ECC
Yes
show more

Storage

Hot-swap HDD bays
Hot-swap HDD bays
Yes
show more


Number of 3.5" bays
Number of 3.5
8
show more


Storage drive sizes supported
Storage drive sizes supported
3.5"
show more


Supported storage drive interfaces
Serial ATA III
show more


RAID levels
RAID levels
0, 1, 5, 10
show more

Graphics

On-board graphics card model
On-board graphics card model
Aspeed AST2500
show more

Network

Ethernet LAN
Ethernet LAN
Yes
show more


Ethernet interface type
Fast Ethernet, Gigabit Ethernet
show more


Ethernet LAN data rates
Ethernet LAN data rates
10,100,1000 Mbit/s
show more

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
show more


USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
show more


Ethernet LAN (RJ-45) ports
Ethernet LAN (RJ-45) ports
2
show more


VGA (D-Sub) ports quantity
VGA (D-Sub) ports quantity
1
show more


Number of SATA III connectors
Number of SATA III connectors
10
show more

Expansion slots

PCI Express slots version
3.0
show more


PCI Express x8 slots
2
show more


PCI Express x16 slots
4
show more

Features

PC health monitoring
CPU, Fan, Temperature
show more


Backplanes support
Yes
show more

Technical details

Compliance certificates
RoHS
show more

Logistics data

Harmonized System (HS) code
84714100
show more

BIOS

BIOS type
BIOS type
UEFI
show more


BIOS memory size
128 Mbit
show more

Design

Chassis type
Chassis type
Rack (4U)
show more


Product colour
Product colour
Black
show more


LED indicators
HDD, Heating, Network, Power
show more


On/off switch
On/off switch
Yes
show more


Number of fans
Number of fans
3 fan(s)
show more

Power

Power supply
Power supply
1200 W
show more

Operational conditions

Storage relative humidity (H-H)
5 – 95%
show more


Operating relative humidity (H-H)
8 – 90%
show more


Storage temperature (T-T)
Storage temperature (T-T)
-40 – 60 °C
show more


Operating temperature (T-T)
Operating temperature (T-T)
10 – 35 °C
show more

Weight & dimensions

Weight
Weight
32.2 kg
show more


Height
Height
452 mm
show more


Depth
Depth
648 mm
show more


Width
Width
178 mm
show more
