Supermicro SYS-F618R2-RC1+ 4U FatTwin DP Server

The Supermicro SuperServer F618R2-RC1+ is equipped with an Intel® C612 motherboard chipset and features an LGA 2011 (Socket R) processor socket, delivering a system bus rate of 9.6 GT/s. It supports DIMM module capacities of 4GB, 8GB, 16GB, 32GB, and 64GB, with a maximum internal memory of 2 TB and a maximum RDIMM memory capacity of 1 TB. For storage, it supports 2.5" drives and interfaces with Serial Attached SCSI (SAS)-3. RAID levels 0, 1, 5, and 10 are also supported. The on-board graphics card model is the Aspeed AST2400. In terms of networking, it supports Fast Ethernet and Gigabit Ethernet, with Ethernet LAN data rates of 10, 100, and 1000 Mbit/s, and utilizes copper Ethernet cabling technology compatible with 10BASE-T, 100BASE-TX, and 1000BASE-T standards.

Processor

Built-in processor
Built-in processor
No
show more


Motherboard chipset
Motherboard chipset
Intel® C612
show more


Processor socket
Processor socket
LGA 2011 (Socket R)
show more


Number of processors supported
Number of processors supported
2
show more


System bus type
QuickPath Interconnect (QPI)
show more


System bus rate
System bus rate
9.6 GT/s
show more


Maximum cache
55 MB
show more


Compatible processor series
Compatible processor series
Intel® Xeon®
show more


Intel Xeon series
E5-2600
show more

Memory

Number of DIMM slots
Number of DIMM slots
16
show more


Supported DIMM module capacities
4GB, 8GB, 16GB, 32GB, 64GB
show more


Maximum internal memory
Maximum internal memory
2 TB
show more


Maximum RDIMM memory
1 TB
show more


Supported RDIMM clock speeds
1600,1866,2133,2400 MHz
show more


Memory form factor
Memory form factor
288-pin DIMM
show more


Memory voltage
Memory voltage
1.2 V
show more


Memory bus
Memory bus
72 bit
show more


ECC
ECC
Yes
show more

Storage

Number of storage drives supported
Number of storage drives supported
6
show more


Hot-swap HDD bays
Hot-swap HDD bays
Yes
show more


Number of 2.5" bays
6
show more


Storage drive sizes supported
Storage drive sizes supported
2.5"
show more


Supported storage drive interfaces
Serial Attached SCSI (SAS)-3
show more


RAID levels
RAID levels
0, 1, 5, 10
show more

Graphics

On-board graphics card model
On-board graphics card model
Aspeed AST2400
show more

Network

Ethernet interface type
Fast Ethernet, Gigabit Ethernet
show more


Ethernet LAN
Ethernet LAN
Yes
show more


Ethernet LAN data rates
Ethernet LAN data rates
10,100,1000 Mbit/s
show more


Copper ethernet cabling technology
10BASE-T, 100BASE-TX, 1000BASE-T
show more


LAN controller
Intel® I350-AM2, Realtek RTL8201N
show more

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
show more


Ethernet LAN (RJ-45) ports
Ethernet LAN (RJ-45) ports
2
show more


IPMI LAN (RJ-45) port
Yes
show more


VGA (D-Sub) ports quantity
VGA (D-Sub) ports quantity
1
show more

Expansion slots

PCI Express x16 (Gen 3.x) slots
PCI Express x16 (Gen 3.x) slots
1
show more


Micro low profile PCI Express slots
1
show more

Features

Backplanes support
Yes
show more

Technical details

Compliance certificates
RoHS
show more

BIOS

BIOS type
BIOS type
AMI
show more


BIOS memory size
128 Mbit
show more


ACPI version
2.0
show more


BIOS features
APM 1.2, PCI 2.2, SMBIOS 2.3, UEFI
show more

Design

Chassis type
Chassis type
Rack (4U)
show more


Product colour
Product colour
Black
show more


LED indicators
HDD, Network, Power, Status
show more


On/off switch
On/off switch
Yes
show more


Fan diameter
Fan diameter
4 cm
show more


Number of fans
Number of fans
3 fan(s)
show more

Power

Power supply
Power supply
2000 W
show more


Redundant power supply (RPS) support
Redundant power supply (RPS) support
Yes
show more


Number of redundant power supplies installed
4
show more

Operational conditions

Storage relative humidity (H-H)
5 – 95%
show more


Operating relative humidity (H-H)
8 – 90%
show more


Storage temperature (T-T)
Storage temperature (T-T)
-40 – 70 °C
show more


Operating temperature (T-T)
Operating temperature (T-T)
10 – 35 °C
show more

Weight & dimensions

Weight
Weight
47.6 kg
show more


Height
Height
177 mm
show more


Depth
Depth
737 mm
show more


Width
Width
448 mm
show more

Packaging data

Package weight
Package weight
68 kg
show more
