Supermicro SuperServer F619P2-RC1 Intel C621 LGA 3647 (Socket P) Rack 4U Black

Introducing the Supermicro SuperServer F619P2-RC1, a high-performance server designed for demanding applications. It features the Intel C621 chipset and utilizes the LGA 3647 (Socket P) processor socket with a system bus rate of 10.4 GT/s. The server supports DDR4-SDRAM memory types and can accommodate up to 1.5 TB of internal memory, including a maximum of 1.5 TB RDIMM memory. It supports storage drives with 2.5" sizes and interfaces with Serial Attached SCSI (SAS)-3 for enhanced data transfer capabilities. The server is equipped with the on-board graphics card model Aspeed AST2500 and offers PC health monitoring for CPU, fans, and temperature to ensure optimal performance and reliability.

Processor

Built-in processor
Built-in processor
No
show more


Motherboard chipset
Motherboard chipset
Intel® C621
show more


Processor socket
Processor socket
LGA 3647 (Socket P)
show more


Number of processors supported
Number of processors supported
2
show more


System bus rate
System bus rate
10.4 GT/s
show more

Memory

Number of DIMM slots
Number of DIMM slots
12
show more


Supported memory types
Supported memory types
DDR4-SDRAM
show more


Maximum internal memory
Maximum internal memory
1.5 TB
show more


Maximum RDIMM memory
1.5 TB
show more


Supported RDIMM clock speeds
2133,2400,2666 MHz
show more


ECC
ECC
Yes
show more

Storage

Number of storage drives supported
Number of storage drives supported
6
show more


Hot-swap HDD bays
Hot-swap HDD bays
Yes
show more


Storage drive sizes supported
Storage drive sizes supported
2.5"
show more


Supported storage drive interfaces
Serial Attached SCSI (SAS)-3
show more

Graphics

On-board graphics card model
On-board graphics card model
Aspeed AST2500
show more

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
show more


IPMI LAN (RJ-45) port
Yes
show more

Expansion slots

PCI Express slots version
3.0
show more


PCI Express x16 slots
2
show more

Features

PC health monitoring
CPU, Fan, Temperature
show more


Backplanes support
Yes
show more

Technical details

Compliance certificates
RoHS
show more

BIOS

BIOS type
BIOS type
EEPROM
show more


BIOS memory size
128 Mbit
show more

Design

Chassis type
Chassis type
Rack (4U)
show more


Product colour
Product colour
Black
show more


LED indicators
HDD, Network, Power
show more


On/off switch
On/off switch
Yes
show more


Fan diameter
Fan diameter
4 cm
show more


Number of fans
Number of fans
3 fan(s)
show more

Power

Power supply
Power supply
2200 W
show more


Redundant power supply (RPS) support
Redundant power supply (RPS) support
Yes
show more


Number of redundant power supplies installed
4
show more

Operational conditions

Storage relative humidity (H-H)
5 – 95%
show more


Operating relative humidity (H-H)
8 – 90%
show more


Storage temperature (T-T)
Storage temperature (T-T)
-40 – 60 °C
show more


Operating temperature (T-T)
Operating temperature (T-T)
10 – 35 °C
show more

Weight & dimensions

Weight
Weight
68 kg
show more


Height
Height
177 mm
show more


Depth
Depth
737 mm
show more


Width
Width
448 mm
show more

Packaging data

Package weight
Package weight
90.7 kg
show more
