Brother TD-4520DN Label Printer

The Brother TD-4520DN is a high-performance thermal printer designed for diverse labeling applications. It uses direct thermal printing technology to produce clear and crisp outputs with a maximum resolution of 300 x 300 DPI. With an impressive printing speed of 203 mm/s, it is ideal for businesses that need efficient and reliable label production.

Featuring a sleek gray and white design, the TD-4520DN not only delivers exceptional performance but also enhances any workspace aesthetic. The printer offers wired connectivity, ensuring stable and secure connections for seamless operation. This model is especially well-suited for industries such as retail, logistics, and healthcare, where accurate labeling is crucial for inventory management and compliance.

Belonging to Brother's renowned line of thermal printers, the TD-4520DN is distinguished by its robust build quality and user-friendly interface. Brother, a trusted name in printing technology, has developed this model to deliver consistent performance, making it a valuable asset for any organization looking to improve its labeling capabilities. Experience the reliability and efficiency that the Brother TD-4520DN brings to your labeling tasks.

Printing

Print technology
Print technology
Direct thermal
show more


Colour
Colour
No
show more


Maximum resolution
Maximum resolution
300 x 300 DPI
show more


Print speed
Print speed
203 mm/sec
show more


Print speed
Print speed
6 lpm
show more


Minimum print length
1.7 cm
show more


Mirror printing
Yes
show more


Text style
Bold, Horizontal lines, Invert, Italic, Normal, Shadow, Shadow light, Surround
show more


Maximum print length
3 m
show more

Paper handling

Core diameter
1.27 cm
show more


Maximum roll diameter
Maximum roll diameter
12.7 cm
show more


Maximum label width
11.8 cm
show more

Ports & interfaces

Connectivity technology
Connectivity technology
Wired
show more


Ethernet LAN
Ethernet LAN
Yes
show more


Wi-Fi
Wi-Fi
No
show more


Bluetooth
Bluetooth
No
show more


USB port
USB port
Yes
show more


USB 2.0 ports quantity
USB 2.0 ports quantity
1
show more


RS-232 ports
RS-232 ports
1
show more

Performance

Page description languages
CPCL-native, DPL, EPL2, ESC P, Raster_P, ZPL II
show more


Internal memory
Internal memory
256 MB
show more


Flash memory
64 MB
show more


Built-in barcodes
CODABAR (NW-7), Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, ITF, POSTNET, UPC-A, UPC-E
show more


Number of fonts
6
show more


Font styles
Brougham,Brussels,Helsinki,Letter Gothic,San Diego
show more

Design

Product colour
Product colour
Grey, White
show more


Built-in display
Built-in display
No
show more


Display
Display
No
show more

Power

Auto power off
Auto power off
Yes
show more

System requirements

Linux operating systems supported
Linux operating systems supported
Yes
show more


Mobile operating systems supported
Mobile operating systems supported
Android 4.1, Android 4.2, Android 4.2.1, Android 4.2.2, Android 4.3, Android 4.4, Android 5.0, Android 5.1, Android 6.0, Android 7.0, Android 7.1, Android 7.1.2, Android 8.0, Android 9.0, iOS 10.0, iOS 11.0, iOS 12, iOS 8.0, iOS 8.1, iOS 8.2, iOS 8.3, iOS 8.4, iOS 9.0, iOS 9.1, iOS 9.2, iOS 9.3
show more


Server operating systems supported
Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
show more


Windows operating systems supported
Windows operating systems supported
Windows 10, Windows 7, Windows 8, Windows 8.1
show more

Operational conditions

Operating relative humidity (H-H)
5 – 40%
show more


Storage relative humidity (H-H)
20 – 85%
show more


Storage temperature (T-T)
Storage temperature (T-T)
-20 – 60 °C
show more


Operating temperature (T-T)
Operating temperature (T-T)
10 – 90 °C
show more

Weight & dimensions

Width
Width
265 mm
show more


Depth
Depth
335 mm
show more


Height
Height
258 mm
show more


Weight
Weight
3.04 kg
show more

Packaging data

Quantity per pack
1 pc(s)
show more


Package weight
Package weight
3.96 kg
show more

Packaging content

Cables included
AC, USB
show more


Starter roll included
Yes
show more


Software development kit (SDK)
Yes
show more


Warranty card
Yes
show more


Quick start guide
Quick start guide
Yes
show more


AC adapter included
Yes
show more

Logistics data

Harmonized System (HS) code
84433210
show more


Pallet gross height
14.4 cm
show more


Pallet gross weight
176.4 kg
show more


Master (outer) cases per pallet
40 pc(s)
show more


Master (outer) cases per pallet layer
8 pc(s)
show more


Layers per pallet
5 pc(s)
show more


Products per pallet
Products per pallet
40 pc(s)
show more

Technical details

Pallet type
800 x 1200 mm
show more

Other features

Date & time printing
Yes
show more


Number of languages
18
show more


Languages support
Languages support
Simplified Chinese, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Hungarian, Italian, Japanese, Norwegian, Polish, Portuguese, Russian, Swedish, Turkish
show more


Country of origin
Country of origin
China
show more


LED indicators
Error, Power, Status
show more


Networking features
10/100BASE-TX
show more
