The UACC-Cable-C6A-CMP by Ubiquiti is a high-performance cable designed for those who need reliable connectivity in structured cabling systems. This Category 6 cable is built to perform in demanding environments, featuring a CMP flame rating which makes it ideal for in-wall installations where fire safety is crucial. With a length of 305 meters (or 1000 feet), it supports extensive network setups while maintaining strong data transmission at speeds of 10/100/1000 Base-T and a reference bandwidth up to 600 MHz.
Constructed with solid bare copper conductors at a gauge of 23 AWG, the cable minimizes signal resistance and enhances overall performance. It includes a low smoke flame retardant PVC jacket, ensuring reliable operation within temperatures from -20 to 60°C, and provides robust protection against external interference with its UTP shielding and anti-crosstalk divider. Its durable design makes installation and handling straightforward, featuring a minimum bend radius of 22.4 mm and a maximum pulling tension of 110 N.
Meeting strict standards such as ANSI/TIA-568-C.2 and ISO/IEC 11801, the UACC-Cable-C6A-CMP is a trusted choice for professionals seeking top-tier networking solutions. Whether for commercial or residential projects, this cable is distinguished by its exceptional build quality and performance, making it an essential component for modern networking infrastructures.
| Mechanical | |
|---|---|
| Box dimensions | 474 x 346 x 458 mm (18.7 x 13.6 x 18") |
| Box weight | 14.8 kg (32.5 lb) |
| Cable length | 305 m (1000 ft) |
| Cable color | White |
| Cable type | Category 6 |
| Shielding type | UTP |
| Flame rating | CMP |
| Conductor wire gauge | 23 AWG |
| Conductor type | Solid bare copper |
| Jacket material | Low smoke flame retardant PVC |
| Jacket diameter | 5.6 ± 0.2 mm |
| Bend radius | Min. 22.4 mm |
| Pulling tension | Max. 110 N |
| Storage temperature | -20 to 75°C (-4 to 167°F) |
| Installation temperature | 0 to 60°C (32 to 140°F) |
| Ambient operating temperature | -20 to 60°C (-4 to 140°F) |
| Anti-crosstalk divider | Yes |
| Ripcord | Yes |
| Data rate | 10/100/1000 Base-T |
| Reference bandwith | Up to 600 MHz |
| Standards | Electrical transmission: ANSI/TIA-568-C.2 (2009) ISO/IEC 11801 (Edition 2.2) IEC 61156-5 (Edition 2.1) Flame test: NFPA 262 (CMP) Material and construction: |
