The Ubiquiti UAP-AC-SHD-5 is a high-performance wireless access point that operates on both 2.4 GHz and 5 GHz frequency bands, providing a maximum data transfer rate of 1000 Mbit/s. It supports multiple security algorithms, including WEP, WPA-Enterprise, and WPA-PSK, ensuring robust protection for your network. The device offers versatile Ethernet LAN data rates with options for 10, 100, and 1000 Mbit/s, and it is equipped with Power over Ethernet (PoE) capability for convenient and flexible installation. The access point comes in a sleek white design and has a maximum power consumption of 20 watts.
| Mechanical | |
|---|---|
| Dimensions | Ø220 x 48.1 mm (Ø8.7 x 1.9") |
| Weight | Without mount: 700 g (1.5 lb) With mount: 830 g (1.8 lb) |
| Hardware | |
| Networking interface | (2) GbE RJ45 ports |
| Power method | PoE+ |
| Power supply | UniFi PoE Switch* *5-packs do not come with PoE adapters. |
| Supported voltage range | 44—57 VDC |
| Max. power consumption | 20W |
| Max. TX power 2.4 GHz 5 GHz |
25 dBm 25 dBm |
| MIMO 2.4 GHz 5 GHz |
4 x 4 4 x 4 |
| Max. data rate 2.4 GHz 5 GHz |
800 Mbps 1.7 Gbps |
| Antenna gain 2.4 GHz 5 GHz |
6 dBi 6 dBi |
| Button | Factory reset |
| Mounting | Wall/ceiling (Included) |
| Ambient operating temperature | -10 to 70° C (14 to 158° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC, cULus |
| Software | |
| WiFi standards | 802.11a/b/g/n/ac/ac-Wave2 |
| Wireless security | WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES) 802.11w (PMF) |
| BSSID | Up to 8 per radio |
| VLAN | 802.1Q |
| Advanced QoS | Per-user rate limiting |
| Power save | Supported |
| Guest traffic isolation | Supported |
| Power save | Supported |
| WMM | Voice, video, best effort, and background |
| Concurrent clients | 1000+ |
| Supported Data Rates (Mbps) | |
| 802.11a | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11b | 1, 2, 5.5, 11 Mbps |
| 802.11g | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11n | 6.5 Mbps to 450 Mbps (MCS0 – MCS23, HT 20/40) |
| 802.11ac | 6.5 Mbps to 1.7Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80) |
