Unboxing the PoE Switch Compatibility Guide for UAPs and UVCs
This guide outlines the compatibility of various UniFi switches with different models of access points (UAPs) and cameras (UVCs). Here is the compatibility information for each model:
AP/Camera Model Compatibility:
– US-8: Compatible with UVC-G3 and UAP (various models including UAP-LR, UAP-PRO, and UAP-AC series)
– US-8-60W: Compatible with UVC-G3 and UAP (various models including UAP-LR, UAP-PRO, and UAP-AC series)
– US-8-150W: Compatible with all listed UAP and UVC models
– US-16-150W: Compatible with all listed UAP and UVC models
– US-24-250W: Compatible with all listed UAP and UVC models
– US-24-500W: Compatible with all listed UAP and UVC models
– US-48-500W: Compatible with UVC-G3-DOME and all listed UAP models except UAP-AC-HD
– US-48-750W: Compatible with UVC-G3-DOME and all listed UAP models except UAP-AC-HD
Special Notes:
– Compatibility with the UniFi switch is indicated by a check mark.
– Certain models, like the UAP-AC-LITE and UAP-AC-LR, manufactured before September 2016, will require the Instant 802.3af Gigabit PoE Converter: INS-3AF-I-G or INS-3AF-O-G.
– Models UAP-AC-IW and UAP-AC-IW-PRO require PoE passthrough, supported by all switches listed except for the US-8 and US-8-60W.
– For some models, the switches provide only 802.3af power, so 802.3at power is required.
| Mechanical | |
|---|---|
| Dimensions | 148 x 100 x 31 mm (5.8 x 3.9 x 1.2") |
| Weight | 432 g (15.2 oz) |
| Enclosure material | SGCC steel |
| Hardware | |
| Management interface | Ethernet In-Band |
| Networking interface | (8) GbE RJ45 ports |
| PoE interface | (4) PoE (Pins 1, 2+; 3, 6-) |
| Total non-blocking throughput | 8 Gbps |
| Switching capacity | 16 Gbps |
| Forwarding rate | 11.9 Mpps |
| Power method | (1) 48V DC, 2A Max. |
| Power supply | External AC/DC adapter: 100-240V AC, 50/60 Hz; 48V DC, 1.25A |
| Supported voltage range | 44–57V DC |
| Max. power consumption | 12W (Excluding PoE output.) |
| Total available PoE | 48W |
| Max. PoE wattage per port by PSE | 15.4W |
| ESD/EMP protection | Air: ± 24kV, contact: ± 24kV |
| Ambient operating temperature | -5 to 45° C (23 to 113° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| LEDs | |
| Ethernet | PoE Link/Speed/Activity |
