USG FLEX100 H Series, 8 Gigabit User-Definable Ports, 1 USB (Device Only)

The Zyxel USG FLEX 100H is a robust network security device designed to provide high-performance firewall protection. It offers a firewall throughput of 3 Gbit/s and a VPN throughput of 0.75 Gbit/s, alongside IPS/IDS throughput of 1500 Mbit/s, ensuring seamless and secure connectivity for businesses. The device efficiently dissipates heat at a rate of 40.365 BTU/h.

It's equipped with comprehensive VPN support including IKEv2, IPSec, and SSL, catering to a wide range of business network security needs. The Zyxel USG FLEX 100H features wired connectivity with Ethernet LAN data rates of 10, 100, and 1000 Mbit/s, facilitating fast and reliable data transfer. Additionally, it comes with an RJ-45 console port for straightforward setup and management.

The device operates with an input current of 2 A and a DC input voltage of 12 V, with a maximum power consumption of 17 W, making it an energy-efficient choice for businesses seeking robust network security solutions.

Data transmission

Firewall throughput
3 Gbit/s
show more


VPN throughput
0.75 Gbit/s
show more


IPS/IDS throughput
1500 Mbit/s
show more

Performance

Heat dissipation
Heat dissipation
40.365 BTU/h
show more

Network

VPN tunnels quantity
50
show more


Number of VLANs
16
show more

Security

VPN support
IKEv2, IPSec, SSL
show more

Ports & interfaces

Connectivity technology
Connectivity technology
Wired
show more


USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
1
show more


Ethernet LAN (RJ-45) ports
Ethernet LAN (RJ-45) ports
8
show more


Console port
RJ-45
show more


Ethernet LAN data rates
Ethernet LAN data rates
10,100,1000 Mbit/s
show more

Power

Input current
2 A
show more


DC input voltage
12 V
show more


Power consumption (max)
Power consumption (max)
17 W
show more

Certificates

Compliance certificates
BSMI, CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD)
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
0 – 40 °C
show more


Storage temperature (T-T)
Storage temperature (T-T)
-30 – 70 °C
show more


Operating relative humidity (H-H)
10 – 90%
show more


Storage relative humidity (H-H)
10 – 90%
show more

Weight & dimensions

Width
Width
216 mm
show more


Depth
Depth
143 mm
show more


Height
Height
33 mm
show more


Weight
Weight
1.04 kg
show more

Packaging data

Package width
Package width
278 mm
show more


Package height
Package height
189 mm
show more


Package depth
Package depth
99 mm
show more


Package weight
Package weight
1.62 kg
show more

Packaging content

Cables included
Power
show more

Other features

VPN throughput
750 Mbit/s
show more


Firewall throughput
Firewall throughput
3000 Mbit/s
show more
