USG FLEX500 H Series, User-definable ports with 2x 2.5G, 2x 2.5G (PoE+) & 8x 1G, 1x USB (device only)

The Zyxel USG FLEX 500H is designed to provide high-performance security with its impressive specifications. It offers a firewall throughput of 10 Gbit/s, ensuring efficient data processing. The VPN throughput is 2 Gbit/s, making it suitable for secure remote connections. Additionally, it provides IPS/IDS throughput of 3500 Mbit/s, enhancing security through intrusion prevention and detection. The device manages heat dissipation effectively at 211.3 BTU/h. It supports multiple VPN protocols, including IKEv2, IPSec, and SSL, offering flexible and robust VPN options. The connectivity technology is wired, with an RJ-45 console port for easy setup and management. The device requires an input current of 4.736 A and a DC input voltage of 19 V. The maximum power consumption is 68 watts, ensuring efficient energy use while delivering powerful performance.

Data transmission

Firewall throughput
10 Gbit/s
show more


VPN throughput
2 Gbit/s
show more


IPS/IDS throughput
3500 Mbit/s
show more

Performance

Heat dissipation
Heat dissipation
211.3 BTU/h
show more

Network

Number of VLANs
64
show more

Security

VPN support
IKEv2, IPSec, SSL
show more

Ports & interfaces

Connectivity technology
Connectivity technology
Wired
show more


USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
1
show more


Ethernet LAN (RJ-45) ports
Ethernet LAN (RJ-45) ports
12
show more


Console port
RJ-45
show more

Power

Input current
4.736 A
show more


DC input voltage
19 V
show more


Power consumption (max)
Power consumption (max)
68 W
show more

Certificates

Compliance certificates
BSMI, CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD)
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
0 – 40 °C
show more


Storage temperature (T-T)
Storage temperature (T-T)
-30 – 70 °C
show more


Operating relative humidity (H-H)
10 – 90%
show more


Storage relative humidity (H-H)
10 – 90%
show more

Weight & dimensions

Width
Width
300 mm
show more


Depth
Depth
182 mm
show more


Height
Height
43.5 mm
show more


Weight
Weight
1.64 kg
show more

Packaging data

Package width
Package width
350 mm
show more


Package height
Package height
149 mm
show more


Package depth
Package depth
244 mm
show more


Package weight
Package weight
2.93 kg
show more

Packaging content

Cables included
Power
show more

Other features

VPN throughput
2000 Mbit/s
show more


Firewall throughput
Firewall throughput
10000 Mbit/s
show more
