RX2520 M5 LFF (rack 2U) with 1x Intel Xeon Silver 4216 16-Core 2.10 GHz, 32GB (1x32GB) 2Rx4 DDR4-2933 R ECC up to 768GB, 12 RAM slots, Hot-Plug option, and 2x hot-plug 450W 94% (CSCI PLATINUM) power supplies.

The Fujitsu PRIMERGY VFY:R2525SC200IN is equipped with an Intel Xeon Silver processor, specifically the 4216 model, running at a frequency of 2.1 GHz. It boasts an internal memory capacity of 32 GB, utilizing DDR4-SDRAM technology for efficient performance. The server supports Ethernet LAN with cabling technology compatible with 10/100/1000Base-T(X) standards. It is equipped with a DVD-RW optical drive for media storage and playback. Powering the system is a 450-watt power supply, and it also includes support for a redundant power supply (RPS) to enhance reliability. The chassis is designed as a 2U rack model, making it suitable for various server rack configurations.

Processor

Processor manufacturer
Processor manufacturer
Intel
show more


Processor family
Processor family
Intel Xeon Silver
show more


Processor model
Processor model
4216
show more


Processor frequency
Processor frequency
2.1 GHz
show more


Processor boost frequency
Processor boost frequency
3.2 GHz
show more


Processor cache
22 MB
show more


Motherboard chipset
Motherboard chipset
Intel® C624
show more


Embedded options available
Yes
show more


Maximum number of SMP processors
2
show more


Execute Disable Bit
Yes
show more

Memory

Internal memory
Internal memory
32 GB
show more


Internal memory type
Internal memory type
DDR4-SDRAM
show more


Memory clock speed
Memory clock speed
2933 MHz
show more


Maximum internal memory
Maximum internal memory
768 GB
show more

Storage

Number of HDDs supported
Number of HDDs supported
4
show more


Supported HDD sizes
Supported HDD sizes
3.5"
show more


RAID support
RAID support
Yes
show more


RAID levels
RAID levels
0, 1
show more


Optical drive type
Optical drive type
DVD-RW
show more

Network

Ethernet interface type
Gigabit Ethernet
show more


Cabling technology
Cabling technology
10/100/1000Base-T(X)
show more


Ethernet LAN
Ethernet LAN
Yes
show more

Ports & interfaces

Ethernet LAN (RJ-45) ports
Ethernet LAN (RJ-45) ports
2
show more


USB 2.0 ports quantity
USB 2.0 ports quantity
1
show more


USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
6
show more


VGA (D-Sub) ports quantity
VGA (D-Sub) ports quantity
1
show more

Expansion slots

PCI Express x8 (Gen 3.x) slots
PCI Express x8 (Gen 3.x) slots
3
show more


PCI Express x16 (Gen 3.x) slots
PCI Express x16 (Gen 3.x) slots
1
show more

Design

Chassis type
Chassis type
Rack (2U)
show more


Rack rails
Yes
show more


Rack mounting
Rack mounting
Yes
show more


Redundant fans support
Yes
show more

Software

Compatible operating systems
Compatible operating systems
Microsoft Hyper-V Server 2016
Microsoft Windows Server 2016 Datacenter
Microsoft Windows Server 2016 Standard
Microsoft Windows Server 2016 Essentials
Microsoft Windows Storage Server 2016 Standard
Microsoft Hyper-V Server 2012 R2
Microsoft Windows Server 2012 R2 Datacenter
Microsoft Windows Server 2012 R2 Standard
Microsoft Windows Server 2012 R2 Essentials
Microsoft Windows Storage Server 2012 R2 Standard
VMware vSphere 6.5
VMware vSphere 6.0
SUSE Linux Enterprise Server 12
Red Hat Enterprise Linux 7
Red Hat Enterprise Linux 6
Univention Corporate Server 4
show more

Processor special features

Intel 64
Yes
show more


Intel Virtualization Technology (VT-x)
Intel Virtualization Technology (VT-x)
Yes
show more


Intel TSX-NI
Yes
show more


Intel VT-x with Extended Page Tables (EPT)
Yes
show more


Intel Virtualization Technology for Directed I/O (VT-d)
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
show more


Intel Trusted Execution Technology
Yes
show more


Enhanced Intel SpeedStep Technology
Yes
show more

Power

Redundant power supply (RPS) support
Redundant power supply (RPS) support
Yes
show more


Power supply
Power supply
450 W
show more


Number of redundant power supplies installed
2
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
5 – 45 °C
show more


Operating relative humidity (H-H)
10 – 85%
show more

Certificates

Certification
CB, RoHS, WEEE, GS, CE, CSAc/us, FCC Class A, ICES-003/NMB-003 Class A, VCCI:V3 Class A + JIS 61000-3-2, EAC, KC, CCC, RCM, BSMI
show more

Weight & dimensions

Width
Width
482.4 mm
show more


Height
Height
86.6 mm
show more


Depth
Depth
770 mm
show more
