TP-LINK TL-XZ000-G3 1-Port Gigabit GPON Terminal

The TP-Link TL-XZ000-G3 1-Port Gigabit GPON Terminal is an optical network terminal designed to deliver high-speed internet access using fiber-optic technology. It comes in a compact black housing, measuring 95 mm in width, 75 mm in depth, and 29.3 mm in height, making it ideal for areas with limited space. This terminal supports various networking standards, including IEEE 802.1Q, IEEE 802.1P, and IEEE 802.3u, as well as ITU standards G.984.1, G.984.3, and G.984.4, ensuring compatibility with a wide range of network protocols. It supports Ethernet LAN data rates of 10, 100, and 1000 Mbit/s to suit different bandwidth needs. The device includes an SC fiber optic connector for connectivity and operates with an output voltage of 9 V and an output current of 0.6 A. It can handle upstream data rates up to 1244 Mbit/s, providing efficient data transmission and high-performance internet connectivity for both residential and commercial applications.

Design

Product type
Product type
Optical network terminal (ONT)
show more


Product colour
Product colour
Black
show more


LED indicators
Yes
show more

Network

Networking standards
Networking standards
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3u
show more


ITU standards
G.984.1, G.984.3, G.984.4
show more


Ethernet LAN data rates
Ethernet LAN data rates
10,100,1000 Mbit/s
show more


Upstream data rate
1244 Mbit/s
show more


Downstream data rate
2488 Mbit/s
show more


Transmission distance (max)
20 km
show more

Management features

Web-based management
Web-based management
Yes
show more


Quality of Service (QoS) support
Yes
show more


Reset button
Yes
show more

Ports & interfaces

Fiber ports quantity
Fiber ports quantity
1
show more


Fiber optic connector
Fiber optic connector
SC
show more


Ethernet LAN (RJ-45) ports
Ethernet LAN (RJ-45) ports
1
show more


DC-in jack
DC-in jack
Yes
show more

Power

Output voltage
9 V
show more


Output current
0.6 A
show more

Sustainability

Sustainability compliance
Yes
show more

Certificates

Compliance certificates
RoHS
show more

Operational conditions

Operating temperature (T-T)
Operating temperature (T-T)
0 – 40 °C
show more


Storage temperature (T-T)
Storage temperature (T-T)
-40 – 60 °C
show more


Operating relative humidity (H-H)
10 – 90%
show more


Storage relative humidity (H-H)
5 – 90%
show more

Weight & dimensions

Width
Width
95 mm
show more


Depth
Depth
75 mm
show more


Height
Height
29.3 mm
show more

Packaging content

AC adapter included
Yes
show more


Quantity per pack
1 pc(s)
show more


Quick start guide
Quick start guide
Yes
show more
